Water Blasters

These units range in PSI from 7,500 to 40,000! We have suitable high pressure cleaners and optimum accessories for any demand. The number of possible applications for modern, professional high pressure cleaners are virtually impossible to estimate. Every cleaning and surface preparation task creates different demands on the machine and its accessories. The spectrum ranges from simple cleaning tasks such as machine maintenance right through to removing concrete.

We combine sophisticated and innovative technology with a service network throughout the world. We aspire to meet both our own, as well as the industry's expectations. These water blasters are built in the latest computerized plants using the most up-to-date technology. without this it would not be possible to to develop and manufacture excellent quality and to deliver it without errors.

Water Blasters

Diesel Powered Water Blasting Unit — 15,000 PSI - 40,000 PSI
Water Blasting Unit

These cold water blasting units have electronically adjustable pump settings ranging from 5,000 psi to 15,000 or 40,000 psi depending on the unit you choose. Pumps are made of hardened stainless steel for extended life spans.

Flow rates of 3.0-3.6 GPM
Units capable of 15,000-40,000 PSI with either electric or diesel engine variations.
Various mounting variations to include skid, trolley, or trailer mounts.
All models include a basic accessory package of: rotary gun and 48” wand, 50 ft of 3/8” hose, and foot/shin shields.

Starting around $53,398.00
Call for price quote
More Information

High Pressure Cleaning — 7,250 PSI - 11,700 PSI

The versatile 500 and 800 series units offers between 7,250 - 11,700 PSI at 6 to 8 GPM utilizing a 45 hp diesel engine. This unit is also capable of producing heat through diesel fired burners that will take the water temperature to 200°F.

Control Monitoring features
Two integrated burners
Naturally, cold water operation is also possible.
Comes with basic accessory package which includes gun, wand, and nozzles, shoulder support, and 33ft remote cable.

Starting around $103,000.00
Call for price quote
More Information

Diesel Water Blaster — 17,400 PSI - 40,600 PSI
Skid or Trailer Mounted

The 170 series water blaster is powered by up to a 130 HP John Deere diesel engine that delivers 2400 RPM. The 130 Series may either be trailer mounted or used as a stationary unit. Delivering up to 40,000 PSI depending on model, this unit is able to tackle the most demanding jobs.

Ultra High Pressure Water Cleaner
Unit generates 2800 bar (40,500psi) @ 8.3 – 18 l/min (2.2 – 4.75 gpm)
Diesel Powered by a John Deere Model BF4M1013FC Engine, Rated 130HP @2,400 rpm
Comes with basic accessory package which includes gun, wand, and nozzles, shoulder support, and 33ft remote cable.

Starting around $124,000.00
Call for price quote
More Information

The Stationary high pressure water blasters of the 250 hp class offer even higher levels of performance. They can attain working pressures of up to 40,600 PSI and delivery rates up to 16.6 GPM.

Control Monitoring features
Wide open access doors on 5 sides
Flexible configurations
Comes with basic accessory package which includes gun, wand, and nozzles, shoulder support, and 33 FT remote cable.

Starting around $220,000.00
Call for price quote
More Information

Water Blaster Safety Equipment

For proper protection use water blaster safety equipment; protective suite, safety goggles, safety boots, hand protection, gloves and more. This is a must when dealing with ultra high pressure (UHP) equipment.

Certified to Regulation 89/686/ EC by an approved Institute Centexbel 0493. CE type inspection no. 04698084
Call for shipping estimate

Turtleskin protective equipment provides protection to users of ultra high pressure (UHP) up to 40,000 PSI. Operators of water blasters need to ensure they have personal protection when using these very high end machines. It is composed of multiple panels that can be replaced individually.

TurtleSkin WaterArmor personal protective equipment has been CE type approved by Centexbel, Montoyerstraat 24, B-1000 Brussels, Belgium (notified body 0493) according to the directive 89/686/EEC. Certificate number: 00101317. We confirm that each product is identical to the item subjected to the type approval.

Ultra High Pressure Hoses

(UHP) Ultra high pressure hoses are designed for waterblasting applications with a standard length of 50 FT. We can provide custom lengths of water blasting hose to your specifications.

Rated 10,000 - 18,120 PSI (depending on model)
Hose ID ranges between 1/4”-1” (depending on model)
Continuous service from 14 – 158°
Synthetic Rubber Tube on Abrasion Resistant Cover
Four to Six high tensile steel spirals
Safety factor of 2.5 to 1
Optional Waterblast Locking Quick-Connect Couplers & Plugs

Ultra High Thermoplastic Pressure Hose Assemblies

With pressure ranging from 20,000 to 55,000 psi, these ultra high pressure hoses give years of service. Typical applications are waterblasting steel pipe, hydrodemolition, oil field snubbing, or chemical injection. Construction is of polyamide core tube and outer cover with high tensile strength wire re-inforcement.

Hose ID Ranges Between .16”-.75” (depending on model)
Continuous service from -40° F to 140° F
Synthetic Rubber Tube on Abrasion Resistant Cover
Four to Eight High Tensile Steel Spirals
Safety Factor of 2.5 to 1
Ends are MNPT or M Type Swivel (depending on model)
Weights vary between 7-71 lbs (depending on model)

Ultra high pressure Foot valves are designed for operation with flexible lances for heat exchangers cleaning applications.

Rated 11,000 to 21,000 PSI Foot Valves
Max temperature of 200-212 °F

Ultra High Pressure Blaster Accessories

Ultra high pressure blaster accessories are not only designed with safety in mind but also efficiency.These ultra high pressure blaster accessories are using European fittings but can be adapted for different connections.

14,500 to 36,000 PSI Floor Cleaners
7,250 to 14,000 PSI Water Sandblasting System
11,600 PSI Ultra High Pressure Rotary Nozzle
Rated 40,600 PSI High Pressure Gun and Attachments

High Pressure Valves

Choose one of these high pressure valves for applications where shutting off flow to pressures of up to 21,000 psi are needed. The high pressure valves are constructed of high grade 316L stainless steel for excellent corossion resistance. Available in multiple connection types ranging from 1/4" to 1/2" for many application types. Valves can accept up to 300 degrees F for hotter fluids.

Water blaster units are used by all types of industries, and by contractors who provide speciality-cleaning services to those industries. They are also widely used by the surface prep industry to remove all sorts of paints and coatings. Essentially, if you have a product that is extremely difficult to remove, water blasters could be your answer.

Pressure and Flow both play key roles in an efficient water blasting system, and applications respond differently to each variable. Typically, hardened deposits respond better to higher pressures, and softer materials are best removed with higher flows. Each application is unique, though, and we can help you determine which combination of pressure and flow will work best for you.

Applications for these ultra high pressure units include:

Debarring System
Sewer Jetting
Hydro demolition Production Rate
Investment Casting Cleaning
Oxidation Removal at 36,000 psi
Chloride Removal from Concrete
Asbestos Removal
Corrosion Removal from Pilings
Historic Cobblestone Restoration
Pool Refurbishing
Marine Surface Prep
Prep for Highway Overlay
Paint Removal from Ships
Water Jet Cutting
Concrete Surface Preparation

Some Applications for Water Blasters

Shuttering Scaffolding

Extension Renovation

Agriculture

Pipes and Sewers

Industry

Transport and Traffic

Local Authorities

Building Industry

Recommended Pressures

The following chart gives estimates for recommended pressures for different applications, based on past experience.
Industry	Applications	Recommended Pressure
		PSI		Bar
		min	max	min	max
Tire Manufacturers	Latex production and storage, reactor cleaning, strippers, mixers vulcanization ovens, pipings	3,627	7,254	250	500
Accumulator factory	container mixers, Floors	2,901	7,254	200	500
Aluminium plant	hardened bauxite dust on mills, filters, floors, tanks, sumps,reactors and sewers	10,155	36,268	700	2,500
Automotive	paint and solder from booths, machinery, grating and conveyors	11,606	36,268	800	2,500
Automotive component suppliers	cleaning of plastic moulds and casting moulds	11,606	21,761	800	1,500
Aviation	expansion joints, road marks, grease, rubber and hydraulic fluids on runways	10,155	36,268	700	2,500
Breweries	yeast, sediments and fermentation residues on vats, pipe and facilities, storage tanks, kegs, filter presses, coolers, evaporators	3,046	5,077	210	350
Carpet manufacturer (synthetic)	removal of latex residues from machinery and storage tanks	3,627	5,077	250	350
Cement plants	removal of dirt, grease and product built-up on grates floors ,external piping, bins , walls hopper cars and handling equipment	3,046	5,077	210	350
	cooler hearths and preheater columns, floors rotary kilns	5,077	10,155	350	700
Ceramic industry Porcelain industry	cleaning of mixers, filters, ovens and kneaders	1,451	5,077	100	350
	cutting of moulded blanks	4,062	4,642	280	320
Chemical processing	removal of chemical residues from boiler tubes, tanks , valves, evaporators, heat exchangers, tube bundles, pipes vessels, reactors and facilities	5,077	36,268	350	2,500
Construction	cleaning of asphalt distributors, mixers, tar cookers and pavers	5,077	7,254	350	500
	exposing aggregate (retarded) Asphalt, dirt concrete, mortar, grease, mastic and clay on vehicles concrete mixing trucks and machinery	5,077	7,254	350	500
	latents for canals, lifts, dams, and runways prior to pours (no retarders)	5,000	10,000	350	700
	exposing aggregate (unretarded), concrete cutting	5,000	40,000	350	2,182
	roughening of concrete prior to coatings	7,254		500
	Removal of extension joints	7,254	11,606	500	800
	demolition and concrete rehabilitation	14,507	36,268	1,000	2,500
	Cleaning of form work	5,077	7,254	350	500
Construction material manufacturers	brick kilns and concrete stone manufacturers: Cleaning of forms, machinery, drains and conveyors. Exposing pebbles in concrete stones, removal of concrete sludge	2,901	7,254	200	500
	gypsum carton manufacturers: Cleaning of conveyors, equipment, floors, mixers, drains	5,077	7,254	350	500
	rockwool manufacturers: removal of residues from machinery	7,254	11,606	500	800
	roof tile and concrete sheet manufacturers: cleaning of forms, sieves, piping, floors, mixers	2,901	7,254	200	500
Dairies	cleaning of floors, containers and machinery	2,176	3,627	150	250
	production of condensed milk: Cleaning of evaporators, coolers, tank trucks , drainage	2,176	5,077	150	350
Facade cleaning, facility management	removal of environmental dirt, graffiti removal, cleaning of tiles and terraces	3,627	7,254	250	500
Farming and animal breeding	cleaning of barns, machinery, drains and corrosion protection of machinery with water sand blasting	2,176	5,077	150	350
Fishing industry, smoke houses	removal of deposits from conveyors , floors, smoke chambers, containers, sewage system and evaporators	2,901	5,077	200	350
Flake board and plywood manufacturers	cleaning of glue containers, mixers and drains	2,901	21,761	200	1,500
Food processing, instant coffee, chocolate, honey, sugar factories, meat, abattoirs	removal of deposits from conveyors, floors, containers, mixers, and filters, drain cleaning, pre-heater cleaning, evaporators, sieves, heat exchangers	2,901	14,507	200	1,000
Foundries	removal of deposits, metal oxides, ceramic and sand sore, materials for casting, furnaces and paddles	7,254	36,268	500	2,500
	aluminium casting : Removal of founders black, sand core removal in waste wax process	3,627	7,254	250	500
	steel investment casting: ceramic core removal especially out of tapped blind hole	11,606	17,408	800	1,200
Highway maintenance	removal of grease,vegetation, mud, tar, cement or asphalt from vehicles and machinery	5,077	11,606	350	800
	graffiti, stains, tar and mastics on concrete bridges and overpasses	10,000	40,000	700	2,812
	removal of extension joints	10,155		700
	removal of paint strips	10,155	36,268	700	2,812
	unstop culverts on bridges and clean up overspills	10,000	40,000	700	2,500
	cleaning of drains and ducts	2,176	7,254	150	500
Marine	removal of marine growth, barnacles, loose paint and rust from vessels, docks, ballast tanks, platforms, storage tanks, and boilers	7,254	14,507	500	1,000
	underwater cleaning of pipe and drilling platforms of barnacles and marine growth to "white metal"	40,000		2,812
	paint stripping from ship hulls up to surface quality SA 2 1/2	36,268	43,521	2,500	3,000
Meat packing	cleaning of grease, fats, blood and soot from oven mixers, vats and conveyors	2,176	3,627	150	250
Metal working	removal of mill scale, rust, welding slag from new vessels, tanks and pipe	7,254	36,268	500	2,500
Mining	premaintenance cleaning of dumpers, drag lines, underground haulage lines and shafts - aids in the recovery of the ore	7,254	10,155	500	700
	unclog plant machinery due to coal, rock dust, mud, or oils	10,000		700
	filter cleaning, conveyors, valves	2,901	7,254	200	500
Municipalities	cleaning of water reservoirs, sewage plants, sanitation equipment, refuse vehicles, containers, sewer and drain pipes	3,046	5,077	210	350
	water reservoirs: removal of coatings, concrete rehabilitation	14,507	36,268	1,000	2,500
Oilfield	paraffine and crude residues on platforms and storage tanks	3,046	5,077	210	350
	removal of drilling mud and cement from drilling pipes	3,046	5,077	210	350
Paint manufacturers	cleaning of pigment manufacturing equipment	2,901	3,627	200	250
	cleaning of paint mixing drums	5,803	14,507	400	1,000
	floor cleaning	7,254		500
	autoclave cleaning	5,077	7,254	350	500
Painters	facade preparation prior to coatings, latex paint removal	4,352	11,606	300	800
	removal of corrosion protection coatings from metal installations	7,254	36,268	500	2,500
Petrochemical processing	algae, carbon, scum and asbestos in heat exchangers, soft polymers, re-boilers, tanks, reactors, cooling towers and facilities.	5,077	36,268	350	2,500
	calcium carbonate and sulphate, chlorides, hard polymers, iron oxide, coke, hard carbon PVC and PVA on heat exchangers or reboilers	10,155	36,268	700	2,500
Pharmaceutical	cleaning of chemicals (liquid and solids) from pipe, kettles, mixers, tubes, heat exchangers, reactors, filters and evaporators	7,689	36,268	530	2,500
Pipe (industrial)	removal of rust and varnish prior to re-coating, dope and oil from pipe threads for inspection, drilling mud and debris in various kinds of pipe (internal)	10,155	36,268	700	2,500
Power station	nuclear decontamination of fuel capsules, "U" tube exchangers, flash from pre-heater tubes, hand tools and equipment, Filters, coolers	5,077	36,268	350	2,500
	removal of coatings (ceramic) and deposits from gas turbines	21,761	36,268	1,500	2,500
	cleaning of turbine blades in water power stations from scale	14,507	17,408	1,000	1,200
Public utility	reactors and insulators, boiler tubes, vehicles and machinery	5,077	10,155	350	700
Pulp & paper	cleaning of grease, oil, pitch dirt, and wood pulp from heat exchangers, tubes, foundries, press sections of paper machines, suction rolls, stock chests and lines	7,689	14,507	530	1,000
	Black liquor	10,155		700
Railroad	gypsum, potash, cement, lime in hopper cars ; removing grease, dirt and deposits in truck and undercarriages and tank cars	5,077	14,507	350	1,000
Refineries	wax, paraffin, grease and crude residues	3,046		210
	water scale, coke, hard carbons and polymers in heat exchangers, pipe tubes and tanks.	10,155	36,268	700	2,500
	Distillation columns, filters	11,606	17,408	800	1,200
Rubber Processing	chemigum, latex, SBR and water scale in reactors, storage tanks, heat exchangers, tubing, pipe and facilities	10,155	36,268	700	2,500
Steel Mill	water scale, coke, ore or lime in heat exchangers, flues, boilers, open hearths, furnaces, chutes and hoppers	7,254	36,268	500	2,500
Surface preparation	paint, rust, refractory buildup, salts, concrete and marine growth	10,155	15,377	700	1,060
	Cleaned to "white metal"		36,268		2,500
Synthetic fibre industry	pipes, heat exchanger, tanks container, mixers	2,176	14,507	150	1,000
Textile industry	dyeing tanks, transportation containers, removal of fluff balls	2,901	5,077	200	350
